DHCP Configuration on Cisco's Router



1. DHCP stands for "Dynamic Host Configuration Protocol".
2. DHCP works on Application Layer of TCP/IP model.
3. DHCP assign the automatic ip address to dhcp client.
4. The port number of dhcp server is 67(DHCP Server) & 68(DHCP Client)
5. DHCP scope is the start & end range of ip address that is assigned to dhcp client by dhcp server.

APIPA:- Automatic Private IP Addressing (APIPA) is a feature of Windows-based OS included since Windows 98 and Windows ME. It enables a Dynamic Host Configuration Protocol client to automatically assign an IP address to itself when there's no DHCP server available to perform that function.

Range of APIPA IP Address is  169.254. 0.1 to 169.254. 255.254.

                      DORA (Discover Offer Request Acknowledgment) Concept

                      -----------------------------------------------------------------------------------



Download link for Practical of DHCP-Single Pool:)

https://mega.nz/file/hXgEjb5Q#2Wip8rmacbM9eVbPQsuTiQ85It8CauupxcCfZGhvkPU

Assign the ip address on Fast Ethernet 0/0 on Cisco Router's

Router(config)#int f 0/0

Router(config-if)#ip add 192.168.10.1 255.255.255.0

Router(config-if)#no shutown

DHCP Configuration on Cisco Router's

Router(config)#ip dhcp pool abhishek

Router(dhcp-config)#network 192.168.10.0 255.255.255.0

Router(dhcp-config)#default-router 192.168.10.1

Router(dhcp-config)#dns-server 8.8.8.8

Router(dhcp-config)#exit

Router(config)#

Download link for Practical of DHCP-Multiple Pool:)

https://mega.nz/file/1e4lGTKZ#HMWc1uOY2gqxIbvKfgcZBXJO0i_X2V2OpnqYHZuQrVE

Assign the ip address on Fast Ethernet 0/0 on Cisco Router's

Router(config)#int f 0/0

Router(config-if)#ip add 192.168.10.1 255.255.255.0

Router(config-if)#no shutown

Router(config-if)#exit

Router(config)#

Assign the ip address on Fast Ethernet 0/1 on Cisco Router's

Router(config)#int f 0/1

Router(config-if)#ip add 192.168.11.1 255.255.255.0

Router(config-if)#no shutown

Router(config-if)#exit

Router(config)#

DHCP Configuration on Cisco Router's

Router(config)#int f 0/0

Router(config)#ip dhcp pool Manufacturing_Department

Router(dhcp-config)#network 192.168.10.0 255.255.255.0

Router(dhcp-config)#default-router 192.168.10.1

Router(dhcp-config)#dns-server 8.8.8.8

Router(dhcp-config)#exit

Router(config)#

Router(config)#int f 0/1

Router(config)#ip dhcp pool Sales_Department

Router(dhcp-config)#network 192.168.11.0 255.255.255.0

Router(dhcp-config)#default-router 192.168.11.1

Router(dhcp-config)#dns-server 8.8.8.8

Router(dhcp-config)#exit

Router(config)#

Download link for Practical of DHCP-Excluded Address:)

https://mega.nz/file/BWAG2QBZ#E9sqF3nEJLHJF2wGZQrVuKccrziqBXuCLsdotrMyWvM

Assign the ip address on Fast Ethernet 0/0 on Cisco Router's

Router(config)#int f 0/0

Router(config-if)#ip add 192.168.10.1 255.255.255.0

Router(config-if)#no shutown

Router(config-if)#exit

Router(config)#

Assign Excluded-Address on Cisco Router's

Router(config)#ip dhcp excluded-address 192.168.10.2 192.168.10.10

Router(config)#ip dhcp pool Manufacturing_Department

Router(dhcp-config)#default-router 192.168.10.1

Router(dhcp-config)#network 192.168.10.0 255.255.255.0

Router(dhcp-config)#dns-server 8.8.8.8
